Hikvision HiLook NVR-232MH-K/16P 32CH, 2x HDD Bay, 16 PoE, 8MP Resolution
SKU: NVR232MHK16P
$717.00
The Hikvision HiLook NVR-232MH-K/16P 32CH, 2x HDD Bay, 16 PoE, 8MP Resolution is a 32-channel network video recorder designed for mid-to-large IP camera deployments. Supplied by Uniview, this centralised recording platform integrates 16 built-in PoE ports to support direct power and data delivery to compatible cameras.
Key Features
- 32-channel network video recorder
- 16 built-in PoE ports
- 2x HDD bays for storage expansion
- Supports 8MP resolution
- Model: NVR-232MH-K/16P
- Vendor: Uniview
Technical Specifications
| Channel Capacity | 32 IP cameras |
| PoE Ports | 16-ch, IEEE 802.3 af/at, max 150W total |
| Max Recording Resolution | 8MP |
| Supported Resolutions | 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Video Compression | H.265+, H.265, H.264+, H.264 |
| HDMI Output | 1-ch, 4K (3840×2160) / 30Hz, 1920x1080p / 60Hz |
| VGA Output | 1-ch, 1920x1080p / 60Hz, 1280×1024 / 60Hz, 1280×720 / 60Hz |
| Incoming Bandwidth | 160 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| HDD Bays | 2x SATA, up to 8TB per drive |
| USB Ports | 2x USB 2.0 |
| Network Interface | 1x RJ-45 10/100/1000 Mbps Gigabit self-adaptive |
| Synchronous Playback | 16-ch |
| Power Supply | 100-240V AC, 50-60 Hz |
| Power Consumption (unit only) | 15W (excluding PoE load) |
| Working Temperature | -10 to +55 degrees C |
| Chassis | 1U, 385 x 315 x 52 mm |
| Weight | 2.6 kg (without HDDs) |
