Hikvision Ds-kaw60-2n 60w 24vdc Power Supply With 2-wire IP Distributor Support, Din Rail Mounting & 85–264vac Input
SKU: DSKAW602N
$102.75
The Hikvision DS-KAW60-2N 60W 24VDC Power Supply is a DIN rail-mounted adapter engineered for 2-wire IP video intercom distributor installations. It provides a 24VDC output with 60W capacity and supports a wide 85–264VAC input range, ensuring compatibility with standard AC power environments in structured intercom cabinets and low-voltage equipment layouts.
Key Features
- 24VDC output with 60W power capacity
- Wide 85–264VAC input range
- DIN rail TS35 mounting support
- Compatible with Hikvision DS-KAD706 series 2-wire IP distributors
- Ultra-thin 53.5mm design for compact enclosures
- Built-in LED power status indicator
- Low no-load loss for efficient operation
Technical Specifications
| Model | DS-KAW60-2N |
| Product Type | 60W 24VDC DIN rail power supply |
| Primary Use | 24VDC power supply for compatible Hikvision 2-wire IP video intercom distributors |
| Compatible Application | Power supply for supported DS-KAD706 series 2-wire IP distributor installations |
| Input Voltage | 85VAC to 264VAC |
| Output Voltage | 24VDC |
| Output Power | 60W |
| No-Load Loss | 0.3W |
| Power Indicator | LED light for indicating power status |
| Power Source Rating | LPS passed, limited power source |
| Design | Ultra-thin 53.5mm design |
| Mounting | DIN rail TS35 / 7.5 or 15 installation |
| Working Temperature | -30°C to 70°C |
| Working Humidity | 20% to 90% |
| Dimensions | 52.5 × 90 × 54.5mm |
| Best Use | 2-wire IP intercom distributors, intercom cabinets, low-voltage enclosures, apartment intercom systems and commercial video intercom installations |
| Installation Consideration | Confirm connected load, distributor compatibility, DIN rail space, AC input supply and electrical installation requirements before use |
