Hikvision Ds-kaw150-4n 150w 48v Power Adapter With Short Circuit Protection, LED Power Indicator & Natural Air Cooling
SKU: DSKAW1504N
$188.16
The Hikvision DS-KAW150-4N 150W 48V Power Adapter is a dedicated power supply unit engineered for stable 48VDC output in professional video intercom and low-voltage system installations. Designed with integrated safety mechanisms and a compact form factor, this adapter supports reliable power delivery for structured intercom cabinets and equipment rooms.
Key Features
- Delivers 150W output power at 48VDC with a 3.2A output current capacity
- Supports a wide 100VAC to 240VAC input range for versatile installation environments
- Incorporates short circuit, overload, and over-voltage protection for enhanced system safety
- Utilizes natural air cooling to reduce moving parts and maintain clean cabinet layouts
- Features an integrated LED power indicator for immediate visual status verification
- Constructed with a 105°C long-life electrolytic capacitor for extended operational durability
Technical Specifications
| Model | DS-KAW150-4N |
| Product Type | 150W 48V Power Adapter |
| Primary Use | 48VDC power supply for compatible Hikvision video intercom and low-voltage system equipment |
| Input Voltage | 100VAC to 240VAC |
| Output Voltage | 48VDC |
| Output Current | 3.2A |
| Output Power | 150W |
| Protection Features | Short circuit protection, overload protection and over-voltage protection |
| Cooling System | Natural air cooling / convection |
| Power Indicator | LED power indicator |
| Capacitor | 105°C long-life electrolytic capacitor |
| Surge Tolerance | 5 seconds 300VAC surge voltage input tolerance |
| Noise and Ripple | <150mVpp at 25°C |
| Working Temperature | Operating: -10°C to 70°C; Storage: -25°C to 85°C |
| Working Humidity | <95%, no condensation |
| Dimensions | 105 × 90 × 54.5mm |
| Weight | Approx. 0.54kg |
| Best Use | Hikvision video intercom systems, 2-wire HD intercom installations, low-voltage equipment cabinets and compatible 48VDC device power requirements |
| Installation Consideration | Confirm connected device load, voltage requirement, ventilation, cable path and electrical installation requirements before use |
