Hikvision Ds-6908udi(c) 4K UHD Video Wall Decoder – 8 HDMI Outputs, 64-channel Decoding, Alarm I/o

The Hikvision DS-6908UDI(C) 4K UHD Video Wall Decoder is designed for high-density surveillance environments, capable of decoding up to 64 channels at 1080p or 4 channels at 24MP simultaneously. This unit provides flexible display management through 8 HDMI outputs supporting 4K @ 30Hz, enabling complex split-screen layouts and scene switching for comprehensive monitoring operations.

Key Features

• Decodes up to 64 channels at 1080p, 8 channels at 12MP, or 4 channels at 24MP
• 8 HDMI outputs supporting 4K @ 30Hz and 4 BNC outputs for flexible display integration
• Supports split-screen layouts from 1 to 36 windows with up to 64 saved scenes and 256 auto-switching plans
• Connectivity includes 2 RJ45 Gigabit Ethernet ports, 2 optical Ethernet ports, RS-232, and RS-485 interfaces
• Features 8 alarm inputs and 8 alarm outputs for external security device integration
• Compatible with H.265+, H.265, H.264+, H.264, Smart264, Smart265, MJPEG, and HIK264 compression formats
• Supports ONVIF, GB28181, and SDK protocols for seamless system integration
