Hikvision Ds-2cd6d42g0-is: Dual-directional 4MP Panovu Camera For Comprehensive Surveillance

Hikvision Ds-2cd6d42g0-is: Dual-directional 4MP Panovu Camera For Comprehensive Surveillance
SKU: DS2CD6D42G0IS
$857.40

The Hikvision DS-2CD6D42G0-IS is a dual-directional 4MP PanoVu network camera engineered for bidirectional surveillance in intersections, corridors, and transport hubs. By consolidating two independent lenses into a single IP67 and IK10-rated housing, this unit provides comprehensive coverage from one mounting point while maintaining high-resolution imaging in low-light conditions.

Key Features

  • Dual-lens PanoVu design captures two separate directions simultaneously from a single mounting point
  • 4MP resolution per channel with a maximum output of 2688 x 1520 pixels
  • DarkFighter low-light performance rated at 0.005 lux colour and 0.001 lux black-and-white, dropping to 0 lux with IR active
  • 2-channel WDR and 3D digital noise reduction ensure usable image quality across mixed lighting conditions
  • IP67 ingress protection and IK10 vandal resistance for harsh outdoor and exposed environments
  • Power over Ethernet (PoE) support combines data and power transmission over a single cable run
  • H.265 compression optimizes storage and bandwidth requirements for dual-channel video streams
  • Integrated microphone captures on-site audio alongside the video stream

Technical Specifications

Model DS-2CD6D42G0-IS
Camera Type Dual-directional PanoVu network camera
Image Sensor 1/3″ Progressive Scan CMOS (per channel)
Video Resolution 2688 x 1520 (4MP) per channel
Frame Rate Up to 25 fps (50Hz) / 30 fps (60Hz)
Minimum Illumination (Colour) 0.005 Lux @ F1.2, AGC ON
Minimum Illumination (B/W) 0.001 Lux @ F1.2, AGC ON
Minimum Illumination (IR) 0 Lux with IR active
Lens Options 2.8mm, 4mm, 6mm fixed lenses
Shutter Speed 1s to 1/100,000s
Wide Dynamic Range 2-channel WDR
Noise Reduction 3D Digital Noise Reduction (DNR)
Video Compression H.265, H.264, MJPEG
Audio Built-in microphone
Ingress Protection IP67 (dust and water resistance)
Vandal Rating IK10
Operating Temperature -40°C to 60°C
Operating Humidity 95% or below (non-condensing)
Power Input PoE (Power over Ethernet)
Dimensions 164.3 x 84.6 x 67.4 mm
Weight Approx. 770g
