Hanwha Wisenet PNM−9022V Hanwha Wisenet 8MP Outdoor Multi Sensor Panoramic Camera, 209/180deg, **SPECIAL ORDER**
SKU: HANPNM9022V
$2,439.59
The Hanwha Wisenet PNM−9022V Hanwha Wisenet 8MP Outdoor Multi Sensor Panoramic Camera, 209/180deg, **SPECIAL ORDER** from Hikvision is a multi-sensor panoramic solution designed for wide-area outdoor surveillance. It integrates four independent 2MP sensors to deliver up to 8.3MP of combined resolution across a selectable 180-degree or 209-degree field of view, reducing the need for multiple camera channels in large open facilities.
Key Features
- Four independent 2MP sensors providing up to 8.3MP combined resolution
- Selectable panoramic field of view of 180 degrees or 209 degrees
- 2.8mm fixed lenses on all four sensors
- Digital PTZ capability for post-capture zoom into regions of interest
- WiseStream II technology for bandwidth-efficient streaming
- Dual Micro SD card slots supporting up to 1TB of edge storage
- IP66 and IK10 ratings for outdoor and vandal-resistant deployment
Technical Specifications
| Combined Resolution | Max. 8.3MP (4 x 2MP sensors) |
| Panoramic Coverage Modes | 180 degrees or 209 degrees (selectable) |
| Lens | 2.8mm fixed lens x4 |
| Video Compression | H.265, H.264, MJPEG |
| WiseStream II | Supported |
| Digital PTZ | Supported |
| Analytics | Tampering detection, heatmap |
| Min. Illumination (Colour) | 0.03 lux (F1.6, 1/30sec) |
| Min. Illumination (B/W) | 0.003 lux (F1.6, 1/30sec) |
| Ingress Protection | IP66 |
| Vandal Resistance | IK10 |
| Edge Storage | Dual Micro SD/SDHC/SDXC slots, up to 512GB per slot |
| Operating Temperature | -40°C to 55°C |
| Dimensions | 253 x 165mm |
| Weight | 3.2kg |
| Availability | Special order, 6-8 week lead time |
