Hanwha Vision Hv-ane-l7012r 4MP H.265 Nw IR Flateye Camera
SKU: HVANEL7012R
$332.09
The Hanwha Vision HV-ANE-L7012R is a 4MP network camera designed for indoor ceiling and wall installations where a low-profile, discreet form factor is required. Featuring a flush-mount Flateye housing, the unit blends into ceilings in environments such as lift lobbies, corridors, and retail floors while delivering high-resolution surveillance footage.
Key Features
- 4MP sensor with 2560 x 1440 resolution and a built-in 3mm fixed lens
- Flateye design for flush, low-profile mounting on ceilings and walls
- 120dB Wide Dynamic Range (WDR) for clear imaging in backlit and mixed lighting conditions
- H.265 and H.264 compression with WiseStream II bandwidth optimisation
- Hallway view mode supporting a vertical 9:16 aspect ratio for corridor monitoring
- Day and Night ICR filter for automatic transition between lighting conditions
- Onboard microSD storage support up to 128GB
- IP67 and IK10 ratings for enhanced durability in indoor environments
Technical Specifications
| Model | HV-ANE-L7012R |
| Resolution | 4MP (2560 x 1440) |
| Lens Type | Fixed 3mm |
| Frame Rate | 30fps at all resolutions |
| Video Compression | H.265 / H.264 / MJPEG, multiple streaming |
| Day/Night | Day and Night with ICR (mechanical IR cut filter) |
| Minimum Illumination | Colour: 0.13 Lux (F1.6, 1/30s) / B/W: 0 Lux (IR LED on) |
| Wide Dynamic Range | 120dB |
| IR Viewable Length | 20m (65.62ft) |
| Onboard Storage | Micro SD/SDHC/SDXC slot, up to 128GB |
| Power | PoE (Power over Ethernet) |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 |
| Image Features | Hallway view, WiseStream II, LDC (Lens Distortion Correction) |
| Analytics | Motion detection, tampering, defocus detection, virtual area (intrusion/enter/exit), virtual line (crossing/direction) |
| Form Factor | Flateye (flat-profile ceiling/wall mount) |
